Free browser game · real physics · no download

Design it. Launch it.
Learn why it flew.

Rocket Lab is an engineering puzzle. Stack engines, tanks and decouplers on a budget, then fly them on a full-scale Earth with real gravity, a real atmosphere and real orbits. When something breaks, the game tells you exactly what and why.

Total Δv
10.34 km/s
Liftoff TWR
2.72
Mass
8.12 t
Cost
$1.22M
13.5 m⌀ 1.20 mSTAGE 2STAGE 1Nose cone SCd 0.3 vs 0.85 for a flat topKestrel Vacuum28 kN · Isp 345 s vacDecouplerdrops 920 kg of empty stageKestrel ×9 Cluster235 kN · Isp 325 s vac
DWG CF-RL-001VEHICLE Two-stage orbitalSCALE As shownREV A
6,371 kmEarth radius, to scale
7.8 km/ssideways speed you need for orbit
90 kPaair pressure that breaks your rocket
8missions, one big idea each

How it works

Build, fly, fail, fix.

The loop real engineers use, minus the explosions costing you anything.

  1. 01

    Design

    Stack a command part, tanks, engines and decouplers. The builder works out Δv, thrust-to-weight, burn time and cost for every stage as you build.

  2. 02

    Fly

    Ignite, ease off through Max-Q, pitch east and stage at burnout. Time-warp the long coasts and plan your burns from the map.

  3. 03

    Learn

    Every flight ends with telemetry, a full flight log and a plain-English explanation of what broke and why. Then make it cheaper for three stars.

The missions

From a first hop to orbit and back.

Each mission unlocks the next and is built around one idea from rocket science. Pass it to move on, or fly it on a smaller budget for three stars.

No.MissionYou learnKey equation
01LiftoffReach an altitude of 5 km.Thrust-to-weight ratioTWR = F / (m · g)
02Thin AirReach 40 km without breaking up.Drag and Max-Qq = ½ ρ v²
03Kármán LineReach space: 100 km altitude.The rocket equationΔv = Isp · g₀ · ln(m₀ / m₁)
04Dead WeightCarry a 250 kg satellite to 250 km altitude.StagingΔv total = Δv₁ + Δv₂ + …
05Falling SidewaysReach orbit: periapsis above 120 km.Orbital velocityv = √(GM / r)
06PayloadDeliver a 250 kg satellite to orbit with periapsis above 150 km.Payload fractionpayload fraction = m_payload / m_liftoff
07Station OrbitCircular orbit between 380 and 420 km (both apoapsis and periapsis), engines off.Circularizingε = v²/2 − GM/r
08Coming HomeFly the crew capsule above 100 km and land it at under 10 m/s.Re-entry and terminal velocityv_t = √(2mg / (ρ · C_d · A))

The physics

Not a cartoon.

Everything runs in real units on a planet the size of Earth. Reaching orbit really takes about 9.4 km/s of Δv, and that’s why real rockets are mostly fuel.

Δv = Isp · g₀ · ln(m₀ / m₁)
Tsiolkovsky’s rocket equation, the reason staging exists.
Gravity
Inverse-square, with Earth's real mass. Orbits are actual Kepler ellipses.
Atmosphere
US Standard Atmosphere 1976: density, pressure and temperature up to 140 km.
Engines
Isp changes with outside pressure, so sea-level and vacuum nozzles behave differently.
Drag
Drag rises steeply through the sound barrier, and the shape of the leading part matters.
Heating
Sutton–Graves stagnation heating. Only a heat shield survives a fall from orbit.
Spin
Earth turns at 465 m/s at the equator. Launch east and you get that speed for free.

Your first rocket is four parts away.

Runs in your browser. Your progress and designs are saved on this device.

Start building
